MikroTik | RB1100AHx2

MikroTik RB1100AHx2 1U Rackmount Gigabit Ethernet Router

MikroTik RB1100AHx2 1U rackmount Gigabit Ethernet router


FEATURES: This device is our best performance 1U rackmount Gigabit Ethernet router. With a dual core CPU, it can reach up to a million packets per second . It has thirteen individual gigabit Ethernet ports, two 5-port switch groups, and includes Ethernet bypass capability. 2GB of SODIMM RAM are included, there is one microSD card slot, a beeper and a serial port. The RB1100AH comes preinstalled in a 1U aluminium rackmount case, assembled and ready to deploy.

SPECIFICATIONS: CPU: PowerPC P2020 dual core 1066MHz network CPU with IPsec accelerator. Memory: SODIMM DDR Slot, 2GB installed (RouterOS will use only up to 1.5GB). Boot loader: RouterBOOT, 1Mbit Flash chip. Data storage: Onboard NAND memory chip, one microSD card slot. Ethernet: Thirteen 10/100/1000 Mbit/s Gigabit Ethernet with Auto-MDI/X. Ethernet: Includes switch to enable Ethernet bypass mode in two ports.

Extras: Reset switch, beeper, voltage and temperature sensors. Power options: Built-in power supply (IEC C14 standard connector 110/220V), PoE (12- 24V on port 13). Fan: Built in fans, and Fan headers. Dimensions: 1U case: 44 x 176 x 442 mm, 1275g. Board only: 365g. Operating System: MikroTik RouterOS, Level 6 license.
