FEATURES: Ports 10/100 Fast Ethernet Switch Fabric Forwarding Capacity 5.2 Gbps Type of Ports Available 16 to 28 Ports MAC Address Table Size 8K.

SPECIFICATIONS: Ports 24-10/100Mbps RJ-45 Auto-sensing ports Standards IEEE 802.3 Ethernet IEEE 802.3u Fast Ethernet IEEE 802.3x Flow Control IEEE 802.1p QoS Support (2 Queues) Network Interface RJ-45: 100ohm, UTP/STP cable 10/100Base – EIA/TIA Categories 3 or 5 cable Switching Method Store – and – forward Switch Fabric 4.8Gbps MAC Address Table 8,000 entries Filtering/ Forwarding/LearningRates Full line rate/full wire speed Physical Specifications Dimensions (W x H x D):11.02 x 7.09 x 1.73 in.(280 x 180 x 44 mm) Weight: 4.19 lbs. (1.9 kg.) Metal Housing Side Air Vents with Fanless Air-Cooling Design LEDs 100Mbps – one per port 10Mbps – one per port Power Link/Act (activity)

Power Requirements : Universal AC input: 100 to 240 VAC, 50 to 60 Hz, Internal Universal Power Supply EMC/ Safety Compliances Emissions CE Mark Class A FCC Class A VCCI-A Safety UL Warranty Limited Lifetime
