DLINK | DAP-3690

D-LINK Wireless N Dual-Band PoE Outdoor Access Point

D-LINK DAP-3690 Wireless N Dual-Band PoE Outdoor Access Point


•Network management: Telnet, Secure Telnet (SSH). Web Browser Interface. HTTP, Secure HTTP (HTTPS). SNMP Support. D-View Module - Private MIB. AP Manager II. AP Array. •VLAN/SSID support: Multiple SSID supports up to 16 (8 per radio). •Wireless Frequency Range: 2.4 GHz (2.4 GHz to 2.4835 GHz) 5 GHz (5.15 GHz to 5.35 GHz, 5.47 GHz to 5.85 GHz).
•Security: WPA/WPA2-Personal/Enterprise 64/128-bit WEP. SSID Broadcast Disable. MAC Address Access Control. Rogue AP Detection. 802.1x Authentication. Wireless LAN Partition. •Operating modes: Access Point (AP). WDS with AP. WDS. Wireless Client.
•Dipole antenna gain: 5 dBi @ 2.4 GHz. 7 dBi @ 5 GHz. •Maximum Output Power: 20 dBm @ 2.4 GHz (dual chain). 23 dBm @ 5 GHz (dual chain). •LEDs: Power. LAN. 5 GHz. 2.4 GHz.
